These Pharma Clear Room modules are constructed with 43mm thick insulated panels and anodized aluminium framework. The Pharma Clear Room panels consist of pre-painted galvanized steel for the outer layer and plain galvanized steel for the inner layer. These Pharma Clear Room modules are designed for easy transportation in dismantled form and can be installed at the site without difficulty.

The insulation density in Pharma Clear Room panels is 40kg/cu.mtr. Coil sections in Pharma Clear Room units offer options for chilled water, hot water, or steam with 2, 4, 6, & 8-row depth. SS 304 insulated coil trays in Pharma Clear Room units are fitted with mist eliminators and proper drain traps. Coil face velocity is maintained below 500 fpm. Centrifugal fans of KRUGER/NICOTRA make are installed in Pharma Clear Room units and are AMCA certified.

Pharma Clear Room modules also feature direct-drive fans compatible with BMS systems for energy efficiency. Three-phase induction motors (Eff-1 & 2) from CG/ABB/Kirloskar are used in all Pharma Clear Room units. The centrifugal blower and motor are mounted on a common base frame with spring/rubber anti-vibration isolators. Door limit switches automatically stop the motor/fan when any Pharma Clear Room service door is opened. All doors have aluminium die-cast hinges and nylon handles. Pharma Clear Room units are mounted on base frames made of 16G GI / 100x50mm MS channel, sized to unit capacity, and can be dismantled for easy placement. Custom-made filtration levels are included as per Pharma Clear Room requirements.

Pharma Clean Room – Single Layer Modular Units – Floor Mounted

These Pharma Clear Room units are fabricated using 16G/18G pre-painted or powder-coated galvanized steel panels with anodized aluminium structure. Pharma Clear Room units can be transported in dismantled condition and installed on-site without any difficulty. Centrifugal fans of KRUGER/NICOTRA make are used in all Pharma Clear Room units and are AMCA certified.

Direct-drive fans in Pharma Clear Room units are compatible with BMS systems for energy conservation. Three-phase induction motors (Eff-1 & 2) of CG/ABB/Kirloskar make are used in all Pharma Clear Room units. The centrifugal blower and motor are mounted on a common base frame with anti-vibration spring/rubber isolators. Door limit switches automatically stop the motor/fan when Pharma Clear Room service doors are opened. All doors feature aluminium die-cast hinges and nylon handles. Pharma Clear Room units are mounted on base frames made of 16G GI / 100x50mm MS channel depending on unit size & capacity and can be dismantled for easy placement. Filtration levels are customized as required in Pharma Clear Room units.

Pharma Clean Room – Evaporative Cooling Modular Units – Floor Mounted

These Pharma Clear Room units are made of 16G/18G pre-painted or powder-coated galvanized steel panels with anodized aluminium framework. Pharma Clear Room units are designed for easy transportation in dismantled condition and can be installed at the site without difficulty. Evaporative cooling pads are placed on SS water tanks with mist eliminators, mono-block pumps, and all necessary piping and controls for Pharma Clear Room operation.

Evaporative cooling pad face velocity is maintained below 500 fpm. Centrifugal fans of KRUGER/NICOTRA make are installed in all Pharma Clear Room units and are AMCA certified. Direct-drive fans compatible with BMS systems are provided for energy efficiency. Three-phase induction motors (Eff-1 & 2) of CG/ABB/Kirloskar make are used in all Pharma Clear Room units.

The centrifugal blower and motors are mounted on a common base frame with spring/rubber anti-vibration isolators. Door limit switches automatically stop the motor/fan when Pharma Clear Room service doors are opened. All doors feature aluminium die-cast hinges and nylon handles. Pharma Clear Room units are mounted on base frames made of 16G GI / 100x50mm MS channel depending on size & capacity and can be dismantled for easy placement. Custom filtration levels are provided as required in Pharma Clear Room units.

Insulated / Non-Insulated Storage Chambers – Ground Mounted

These Storage Chambers are fabricated using 43mm thick PU panels with anodized aluminium framework. The chamber panels consist of pre-coated galvanized iron sheet exterior and plain galvanized iron sheet interior. These Storage Chambers are easy to transport in dismantled condition and can be assembled on-site without any hassle.

The density of PU panels is 40 kg/cu.mtr. Cooling assemblies are provided with options of DX or chilled water coils in 2, 4, 6, and 8 rows depending on requirement. Stainless steel drip trays with proper drainage and mist eliminators are installed in all coil sections. Coil face velocity will not exceed 500 fpm. Centrifugal fans from KRUGER/NICOTRA are used in all Storage Chambers and are AMCA certified.

These Storage Chambers also feature direct drive fans compatible with BMS systems for energy optimization. Coil face velocity will not exceed 500 fpm. Three-phase induction motors (Eff-1 & 2) of CG/ABB/Kirloskar make are used in all Storage Chambers.

The centrifugal fan and motor are mounted on a unified base frame with suitable drive package, installed on spring/rubber type anti-vibration isolators. Door limit switches automatically stop the motor/fan when doors are opened. All service doors of the Storage Chambers have aluminium die-cast hinges and nylon handles. Storage Chambers are mounted on base frames of 16G GI / 100x50 mm MS channel, depending on size and capacity, and can be dismantled for easy placement. Custom-made filtration levels are provided in all Storage Chambers.

Single Layer Storage Chambers – Ground Mounted

These Storage Chambers are made of 16G/18G pre-painted or powder-coated galvanized iron sheet panels with anodized aluminium structure. They are designed for easy transport in dismantled condition and can be installed on-site without difficulty.

Centrifugal fans of KRUGER/NICOTRA are used in all Storage Chambers and are AMCA certified. Direct drive fans compatible with BMS systems are provided for energy efficiency. Three-phase induction motors (Eff-1 & 2) of CG/ABB/Kirloskar make are installed in all Storage Chambers.

The centrifugal blower and motor are mounted on a common base frame with suitable drive package, placed on spring/rubber type anti-vibration isolators. Door limit switches automatically stop the motor/fan when doors are opened. All service doors of Storage Chambers have aluminium die-cast hinges and nylon handles. Storage Chambers are mounted on 16G GI / 100x50 mm MS channel base frames according to size and capacity, and can be dismantled for convenient placement. Custom-made filtration levels are included in all Storage Chambers.

Evaporative Storage Chambers – Ground Mounted

These Storage Chambers are fabricated from 16G/18G pre-painted or powder-coated galvanized iron sheet panels with anodized aluminium framework. They are designed for easy transport in dismantled condition and can be installed on-site without any difficulty.

An evaporative cooling pad is installed on a stainless steel water tank with mist eliminator, mono block pump, necessary piping, and control system. Cooling pad face velocity will not exceed 500 fpm. Centrifugal fans of KRUGER/NICOTRA are used in all Storage Chambers and are AMCA certified.

These Storage Chambers feature direct drive fans compatible with BMS systems for energy efficiency. Three-phase induction motors (Eff-1 & 2) of CG/ABB/Kirloskar make are used in all Storage Chambers.

The centrifugal blower and motor are mounted on a common base frame with suitable drive package, fitted on spring/rubber type anti-vibration isolators. Door limit switches automatically stop the motor/fan when doors are opened. All service doors of Storage Chambers have aluminium die-cast hinges and nylon handles. Storage Chambers are mounted on 16G GI / 100x50 mm MS channel base frames depending on size and capacity, and can be dismantled for easy placement. Custom-made filtration levels are provided in all Storage Chambers.
