These units are built using 43mm thick insulated Modular Panels with anodized aluminum framing. The outer and inner skins of the Modular Panels are made of pre-painted and plain galvanized iron sheets respectively. These units can be transported in sections and installed on-site without any difficulty.

The insulation density of the Modular Panels is 40kg/cu.mtr. Heat exchange sections are available with chilled water, hot water, or steam coils in 2, 4, 6, or 8-row options. SS 304 insulated coil trays with mist eliminators and proper drainage are included. Coil face velocity does not exceed 500 fpm. Centrifugal fans of KRUGER/NICOTRA make are used and are AMCA certified.

The units are fitted with direct drive fans compatible with BMS systems for energy efficiency. Three-phase induction motors (Eff-1 & 2) from CG/ABB/Kirloskar are utilized. Centrifugal blower and motor are installed on a common base frame with spring/rubber anti-vibration mounts. Door limit switches trip the motor/fan automatically when doors are opened. Service doors include aluminum die-cast hinges and nylon handles. The base frame is made of 16G GI / 100x50mm MS channel depending on unit size and can be dismantled for easy installation. Filtration levels are customized as required.

Single-Layer Modular Panel Air Treatment Units – Floor Mounted

These AHU’s are manufactured from 16G/18G pre-painted/powder-coated galvanized iron sheet Modular Panels with anodized aluminum framework. The units are easy to transport and install on-site in dismantled form. Centrifugal fans of KRUGER/NICOTRA make are provided and AMCA certified.

Direct drive fans compatible with BMS systems are included to optimize energy use. Three-phase induction motors (Eff-1 & 2) of CG/ABB/Kirloskar make are used. The centrifugal blower and motor sit on a common base frame with a suitable drive package and spring/rubber anti-vibration isolators. Door limit switches automatically trip the motor/fan upon opening. Service doors feature aluminum die-cast hinges and nylon handles. Base frames are 16G GI / 100x50mm MS channel, designed for easy dismantling. Filtration levels are customized as per requirement.

Evaporative Modular Panel Cooling Units – Floor Mounted

These AHU’s utilize 16G/18G pre-painted/powder-coated galvanized iron sheet Modular Panels with anodized aluminum structure. The units are easily transported in sections and installed on-site without difficulty. An evaporative cooling pad is mounted on an SS water tank, with mist eliminator, mono-block pump, piping, and controls included.

Cooling pad face velocity does not exceed 500 fpm. Centrifugal fans of KRUGER/NICOTRA make are used and AMCA certified. Direct drive fans compatible with BMS systems are provided for energy efficiency. Three-phase induction motors (Eff-1 & 2) from CG/ABB/Kirloskar are used.

The centrifugal blower and motor are mounted on a common base frame with spring/rubber anti-vibration isolators. Door limit switches trip the motor/fan automatically when opened. Service doors are equipped with aluminum die-cast hinges and nylon handles. Base frame is made of 16G GI / 100x50mm MS channel depending on size and capacity and can be dismantled for easy placement. Filtration levels are customized as required.
