framework and pre-finished steel surfaces. The panels are designed for quick assembly and can be installed on-site without difficulty.

The ceiling modules include integrated HEPA filtration to maintain ISO ‘5’ conditions in the Operation Theatres. Airflow is controlled to remain below 500 fpm for laminar flow efficiency. All Operation Theatres feature energy-efficient centrifugal fans compatible with BMS systems. Motors used in these Operation Theatres are three-phase induction type (Eff-1 & 2) from CG/ABB/Kirloskar.

The fan and blower assembly in the Operation Theatres is mounted on a common base frame with spring/rubber anti-vibration isolators. Service doors are fitted with limit switches that stop fans when opened. All service doors in the Operation Theatres use aluminum die-cast hinges and nylon handles. The Operation Theatres are designed for easy maintenance and can be dismantled if needed. Filtration levels are customized according to operational requirements.

Operation Theatres – Wall Panel Integrated Systems

These Operation Theatres feature anodized aluminum and pre-coated steel wall panels for durability and sterility. The modular design allows easy transportation and installation of the Operation Theatres without operational disruption.

Clean airflow in the Operation Theatres is maintained through HEPA filtration (99.99% efficiency). Centrifugal fans of KRUGER/NICOTRA make are used in all Operation Theatres and are AMCA certified. Direct drive fans compatible with BMS systems are installed in the Operation Theatres for energy-efficient operation.

Blower and motor assemblies in the Operation Theatres are mounted on anti-vibration isolators to reduce noise. Door limit switches automatically stop fans when any service door is opened. Service doors are equipped with nylon handles and aluminum die-cast hinges. Base frames for the Operation Theatres are made from 16G GI / 100x50 mm MS channels and allow dismantling and repositioning. Filtration levels are customized as per surgical protocols.

Operation Theatres – Evaporative Cooling Configurations

These Operation Theatres are equipped with evaporative cooling pads mounted on SS water tanks, including mist eliminators, mono-block pumps, and piping with controls. Panels are made of 16G/18G pre-painted/powder-coated steel with anodized aluminum framework.

Air velocity through the evaporative cooling pads in the Operation Theatres is kept below 500 fpm to maintain laminar flow. Centrifugal fans of KRUGER/NICOTRA make are used and are AMCA certified. Direct drive fans compatible with BMS systems provide energy-efficient airflow in the Operation Theatres.

Blower and motor assemblies are mounted on a common base frame with spring/rubber anti-vibration isolators. Door limit switches in the Operation Theatres automatically stop fans when opened. Service doors use aluminum die-cast hinges and nylon handles. Base frames of 16G GI / 100x50 mm MS channels allow dismantling and relocation. Filtration levels are customized for each Operation Theatre based on clinical standards.

Operation Theatres – Floor-Mounted Air Supply Systems

Operation Theatres are supported by dedicated floor-mounted air handling units to ensure uninterrupted supply of filtered airflow. The AHUs for Operation Theatres are fabricated with pre-painted or powder-coated steel and anodized aluminum framing.

Centrifugal fans of KRUGER/NICOTRA make supply clean airflow to the Operation Theatres. Blower and fan assemblies are mounted on anti-vibration isolators to minimize operational vibration. Motors used are three-phase induction type (Eff-1 & 2) from CG/ABB/Kirloskar.

Door limit switches on all AHU service doors automatically stop fans when opened. AHUs are mounted on 16G GI / 100x50 mm MS channel base frames for easy dismantling. Filtration levels in the AHUs are customized to meet the specific requirements of each Operation Theatre.
